NH3 gG 200A/400V MET Drošinātājs

ETI kods:: 004113851
Tips:: NH
Izmērs:: NH3
Nominālā strāva:: 200 A
Raksturlielumi:: gG
Indikators:: Viršutinis saugiklio būsenos indikatorius
Nominālais maiņstrāvas spriegums:: 400 V
Atjungimo geba (AC) (kA):: 50 kA
Pd (W):: 12 W
Standarti:: IEC EN 60269-1
Pieteikums:: As metering fuse with strip fuse switch disconnector and fuse switch disconnector

Piederumi

Produkts

Svars: 650 g
Net width: 66 mm
Net height: 151,5 mm
Net depth: 83,6 mm
Stock unit of measure: pcs

Pamata iepakojums

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895618515
Basic packaging weight: 0,69 kg
Basic Packaging Dimensions Height: 0,152 m
Basic Packaging Dimensions Width: 0,09 m
Basic Packaging Dimensions Depth: 0,074 m
Basic packaging volume: 0,001 m³

Transporta iepakojums

Transport packaging quantity: 12 pcs
EAN code for a transport packaging: 3838895618522
Transport packaging weight: 8,632 kg
Transport Packaging Dimensions Height: 0,255 m
Transport Packaging Dimensions Width: 0,295 m
Transport Packaging Dimensions Depth: 0,235 m
Transport packaging volume: 0,018 m³
Pallet quantity: 624 pcs
Customs tariff: 85361090

Rated switching capacity AC: 50 kA
Voltage type: AC
Fuse construction type according to IEC 60269: NH3
Rated voltage AC: 400
Power loss at rated current: 12 W
Type of fuse status indicator: Top fuse status indicator
Rated current: 200 A
Utilization category: gG (cable protection/equipment protection)

ETIM klasifikācija – versija 9.0

Eplan
