NH4a gG 1250A/400V MET Drošinātājs

ETI kods:: 004113861
Tips:: NH
Izmērs:: NH4a
Nominālā strāva:: 1250 A
Raksturlielumi:: gG
Indikators:: Viršutinis saugiklio būsenos indikatorius
Nominālais maiņstrāvas spriegums:: 400 V
Atjungimo geba (AC) (kA):: 50 kA
Pd (W):: 90 W
Standarti:: IEC EN 60269-1
Pieteikums:: As metering fuse with strip fuse switch disconnector and fuse switch disconnector

Produkts

Svars: 2 280 g
Net width: 95 mm
Net height: 200,1 mm
Net depth: 121 mm
Stock unit of measure: pcs

Pamata iepakojums

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895618690
Basic packaging weight: 2,379 kg
Basic Packaging Dimensions Height: 0,1 m
Basic Packaging Dimensions Width: 0,212 m
Basic Packaging Dimensions Depth: 0,152 m
Basic packaging volume: 0,003 m³

Transporta iepakojums

Transport packaging quantity: 4 pcs
EAN code for a transport packaging: 3838400129963
Transport packaging weight: 9,838 kg
Transport Packaging Dimensions Height: 0,255 m
Transport Packaging Dimensions Width: 0,365 m
Transport Packaging Dimensions Depth: 0,25 m
Transport packaging volume: 0,023 m³
Pallet quantity: 144 pcs
Customs tariff: 85361090

Rated switching capacity AC: 50 kA
Voltage type: AC
Fuse construction type according to IEC 60269: NH4a
Rated voltage AC: 400
Power loss at rated current: 90 W
Type of fuse status indicator: Top fuse status indicator
Rated current: 1 250 A
Utilization category: gG (cable protection/equipment protection)

ETIM klasifikācija – versija 9.0
