Residual Current Circuit Breakers (RCCBs) are crucial electrical safety devices that provide protection against electrical shocks and fires. They enhance safety for humans and animals, contributing to a higher level of fire safety. The use of RCCBs is highly recommended in areas with an increased risk of electrical shocks, such as bathrooms, humid and wet rooms, children's rooms, and workshops.

002061672

Attēls no EFI6-P4 A 40/0.3

EFI6-P4 A 40/0.3 RCCB direncālis

ETI kods:: 002061672
Pieteikums:: EN/IEC 61008-1
Nominālā atlikušā strāva:: 0,3 A
Tips:: A
Nominālā strāva:: 40 A
Dziļums:: 70 mm
Montāžas veids:: TH 35
Polu skaits:: 3+N
Nominālā nosacītā īsslēguma strāva Inc (kA):: 6 kA
Izslēgšanas laiks:: Neuždelstas
Nominālais maiņstrāvas spriegums:: 415 V
Nominālā frekvence (Hz):: 50/60 Hz
Nominālais šķērsgriezums:: 125 mm²
Standarti:: EN/IEC 61008-1
IP aizsardzība:: IP20

Produkts

Svars: 0,273 kg
Stock unit of measure: pcs

Pamata iepakojums

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838400152879
Basic packaging weight: 0,303 kg
Basic packaging volume: 0,5 dm³

Transporta iepakojums

Transport packaging quantity: 27 pcs
EAN code for a transport packaging: 3838400152886
Transport packaging weight: 8,484 kg
Transport packaging volume: 17,4 dm³
Pallet quantity: 1 404 pcs
Customs tariff: 85362010

Additional equipment possible: Jā
Rated insulation voltage Ui: 400 V
Built-in depth: 68 mm
Leakage current type: A
Surge current capacity: 0,4 kA
Rated impulse withstand voltage Uimp: 4 kV
Degree of protection (IP): IP20
Mounting method: DIN rail
Rated fault current: 0,3 A
Frequency: 50/60 Hz
Number of poles: 4
Short-circuit breaking capacity (Icw): 6 kA
Rated voltage: 415 V
Rated current: 40 A
Width in number of modular spacings: 4
Ambient temperature during operating(Min): -25 °C
Connectable conductor cross section solid-core(Min): 1 mm²
Connectable conductor cross section multi-wired(Min): 1 mm²
Connectable conductor cross section solid-core(Max): 25 mm²
Connectable conductor cross section multi-wired(Max): 25 mm²
Ambient temperature during operating(Max): 55 °C

ETIM klasifikācija – versija 9.0
