002464161
RBS-BIC Savienojuma modulis
- ETI kods:
- 002464161
- Max. vibration resistance:
- 3 g
- Moduļu skaits:
- 0,5
- Max. shock resistance (g):
- 15 g
- Resistance to humidity:
- 95 % RH
- Funkcija:
- Auxiliary device for centralised control
- Barošanas spriegums (V):
- 240 V
- Kontaktu skaits:
- 1
- Nominālā frekvence (Hz):
- 50/60 Hz
- Terminal screw:
- 1...4
- Tightening torque (Nm):
- 0.8 Nm
- IP aizsardzība:
- IP20
- Montāžas veids:
- TH 35
- Nominālais darba spriegums (V AC):
- 250 V
- Nominālais izolācijas spriegums (V):
- 440 V
- Darba temperatūra:
- -25-70 °C
- Pd (W):
- 0,3 W
4 Dokumenti
15 Loģistika
Produkts
- EAN code for a single product
- 3838400137166
- Svars
- 40 g
- Net width
- 8,8 mm
- Net height
- 90 mm
- Net depth
- 64,7 mm
- Stock unit of measure
- pcs
Transporta iepakojums
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 3838895724179
- Transport packaging weight
- 0,04 kg
- Transport Packaging Dimensions Height
- 92 mm
- Transport Packaging Dimensions Width
- 70 mm
- Transport Packaging Dimensions Depth
- 21 mm
- Transport packaging volume
- 0,135 dm³
- Pallet quantity
- 7 396 pcs
- Customs tariff
- 85389099
8 ETIM
- Built-in depth
- 60 mm
- Mounting method
- DIN rail
- Type of control voltage 1
- AC
- Function
- Electronic for centralized control
- Number of contacts as change-over contact
- 1
- Width in number of modular spacings
- 0,5
- Frequency control voltage 1(Min)
- 50 Hz
- Frequency control voltage 1(Max)
- 60 Hz
ETIM klasifikācija – versija 9.0
1 Diagrammas
0 Programmatūra un draiveri
Programmatūra tiek nodrošināta tāda, kāda tā ir, bez jebkādām garantijām. Autors nav pienākumā sniegt atbalstu, servisu, labojumus vai jauninājumus bezmaksas programmatūrai vai draiberiem.
28 Birkas
002464161Savienojuma modulisRBS-BICETICONmodulārais kontaktorsBistable SwitchRBSAccessoriesSealing coverInternacionālsAutomatizācijas, signalizācijas un vadības ierīcesBistabili slēdži un relejiMax. shock resistance (g): 15 gModuļu skaits: 0,5Nominālais darba spriegums (V AC): 250 VTerminal screw: 1...4Pd (W): 0.3 WDarba temperatūra: -25 °C-70 °CTightening torque (Nm): 0.8 Nm-0.8 NmKontaktu skaits: 1Funkcija: Auxiliary device for centralised controlNominālais izolācijas spriegums (V): 440 VIP aizsardzība: IP20Montāžas veids: TH 35Barošanas spriegums (V): 240 V-240 VResistance to humidity: 95 % RHNominālā frekvence (Hz): 50 Hz/60 HzSavienojuma modulis Moduļu skaits: 0,5 Funkcija: Auxiliary device for centralised control Barošanas spriegums (V): 240 V-240 V Kontaktu skaits: 1 Tightening torque (Nm): 0.8 Nm-0.8 Nm IP aizsardzība: IP20 Montāžas veids: TH 35
