002464162
RBS220-10-12V AC Slēdzis
- ETI kods:
- 002464162
- Funkcija:
- Bistable Switch RBS
- Barošanas spriegums (V):
- 12 V
- I (AC1):
- 20 A
- Sprieguma veids:
- AC
- NO kontaktu skaits:
- 1
- Nominālā frekvence (Hz):
- 50/60 Hz
4 Dokumenti
22 Loģistika
Produkts
- EAN code for a single product
- 3838400145697
- Svars
- 0,137 kg
- Net width
- 35 mm
- Net height
- 90 mm
- Net depth
- 65 mm
- Stock unit of measure
- pcs
Pamata iepakojums
- Basic packaging quantity
- 8 pcs
- EAN code for a basic packaging
- 3838400101747
- Basic packaging weight
- 1,1 kg
- Basic Packaging Dimensions Height
- 94 mm
- Basic Packaging Dimensions Width
- 72 mm
- Basic Packaging Dimensions Depth
- 150 mm
- Basic packaging volume
- 1,015 dm³
Transporta iepakojums
- Transport packaging quantity
- 96 pcs
- EAN code for a transport packaging
- 3838400101754
- Transport packaging weight
- 13,5 kg
- Transport Packaging Dimensions Height
- 215 mm
- Transport Packaging Dimensions Width
- 175 mm
- Transport Packaging Dimensions Depth
- 450 mm
- Transport packaging volume
- 16,931 dm³
- Pallet quantity
- 5 664 pcs
- Customs tariff
- 85364900
2 ETIM
- Mounting method
- DIN rail
- Function
- Mechanical switch
ETIM klasifikācija – versija 9.0
1 Diagrammas
0 Programmatūra un draiveri
Programmatūra tiek nodrošināta tāda, kāda tā ir, bez jebkādām garantijām. Autors nav pienākumā sniegt atbalstu, servisu, labojumus vai jauninājumus bezmaksas programmatūrai vai draiberiem.
21 Birkas
002464162SlēdzisRBS220-10-12V ACEVE/ETIRELBistable SwitchRBS1-pole, 1 module20 A20 AInternacionālsAutomatizācijas, signalizācijas un vadības ierīcesBistabili slēdži un relejiNO/NC kontaktu skaits: 0Sprieguma veids: ACKontaktu skaits: 0Funkcija: Bistable Switch RBSI (AC1): 20 ANO kontaktu skaits: 1Barošanas spriegums (V): 12 V-12 VNominālā frekvence (Hz): 50 Hz/60 HzSlēdzis Funkcija: Bistable Switch RBS Barošanas spriegums (V): 12 V-12 V I (AC1): 20 A Sprieguma veids: AC NO kontaktu skaits: 1 NO/NC kontaktu skaits: 0 Kontaktu skaits: 0
