NH fuse-links with gPV (general Photovoltaic) characteristics are specifically designed for protecting photovoltaic (PV) systems against overcurrent conditions. These fuse-links ensure the safety and reliability of solar power installations by isolating fault currents, preventing damage to PV panels, inverters, and associated wiring.

Šis produkts ir novecojis, un tam nav tieša aizstājēja. Lūdzu, sazinieties ar mūsu tehnisko atbalstu, lai atrastu piemērotu aizstājēju.

004110605 Novecojis

Attēls no *NHS3L gPV 450A/1500V DC

*NHS3L gPV 450A/1500V DC Drošinātājs

ETI kods:: 004110605
Tips:: NH-S
Izmērs:: NH3L
Nominālā strāva:: 450 A
Raksturlielumi:: gPV
Indikators:: Viršutinis saugiklio būsenos indikatorius
Nominālais līdzstrāvas spriegums:: 1500 V
Atjungimo geba (DC) (kA):: 30 kA
L/R (ms):: 3 ms
Pd (W):: 14 W
UL sertificēts:: E347771
Standarti:: IEC 60269-6, UL 248-19
Pieteikums:: Fuse link for DC application. Applied in fuse base PK 3L 1500V

Produkts

Svars: 1 980 g
Net width: 73 mm
Net height: 198 mm
Net depth: 73 mm
Stock unit of measure: pcs

Pamata iepakojums

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895737537
Basic packaging weight: 2,04 kg
Basic Packaging Dimensions Height: 74 mm
Basic Packaging Dimensions Width: 220 mm
Basic Packaging Dimensions Depth: 91 mm
Basic packaging volume: 1,481 dm³

Transporta iepakojums

Transport packaging quantity: 9 pcs
EAN code for a transport packaging: 3838895737544
Transport packaging weight: 18,71 kg
Transport Packaging Dimensions Height: 0,25 m
Transport Packaging Dimensions Width: 0,235 m
Transport Packaging Dimensions Depth: 0,295 m
Transport packaging volume: 0,017 m³
Pallet quantity: 468 pcs
Customs tariff: 85351000

Voltage type: DC
Type of fuse status indicator: Top fuse status indicator
Rated current: 450 A
Utilization category: gPV (photovoltaic protection)

ETIM klasifikācija – versija 9.0
