004672291 Novecojis

* EB2 400/4LCD 250A 4p APGNSC Rūpnieciskais automātslēdzis

ETI kods:: 004672291
Īsslēguma jauda:: 50 kA
Nominālā strāva:: 250 A
Polu skaits:: 4
Kataloga grupa 1:: EB2
Korpusa izmērs:: 250A

Piederumi

Produkts

Svars: 5,7 kg
Net width: 185 mm
Net height: 260 mm
Net depth: 145 mm
Stock unit of measure: pcs

Transporta iepakojums

Transport packaging quantity: 1 pcs
EAN code for a transport packaging: 3838895703815
Transport packaging weight: 5,7 kg
Transport packaging volume: 9 dm³
Pallet quantity: 140 pcs
Customs tariff: 85362090

Motor drive optional: Jā
Rated permanent current Iu: 250 A
Degree of protection (IP): IP20
Type of control element: Rocker
Integrated earth fault protection: Jā
Type of electrical connection of main circuit: Screw connection
Number of poles: 4
Device construction: Built-in device fixed built-in technique
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz: 50 kA
With switched-off indicator: Jā
Overload release current setting(Min): 100 A
Adjustment range short-term delayed short-circuit release(Min): 250 A
Adjustment range undelayed short-circuit release(Min): 1 400 A
Adjustment range short-term delayed short-circuit release(Max): 2 500 A
Overload release current setting(Max): 250 A
Adjustment range undelayed short-circuit release(Max): 3 250 A

ETIM klasifikācija – versija 9.0
