MOD. GSMF T123 275/25 G Pārsprieguma ierobežotājs

ETI kods:: 002440785
Funkcija:: SPD
Lai lietotu ar:: ETITEC GSMF T123
Pašreizējais veids:: AC
Iimp(10/350) Impulsu strāva [kA]:: 25 kA
In (8/20):: 25 kA

Piederumi

Lietošanas instrukcija

Produkts

Svars: 0,095 kg
Stock unit of measure: pcs

Pamata iepakojums

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838400128294
Basic packaging weight: 0,103 kg
Basic Packaging Dimensions Height: 91 mm
Basic Packaging Dimensions Width: 41 mm
Basic Packaging Dimensions Depth: 48 mm
Basic packaging volume: 0,179 dm³

Transporta iepakojums

Transport packaging quantity: 16 pcs
EAN code for a transport packaging: 3838400128287
Transport packaging weight: 1,729 kg
Transport Packaging Dimensions Height: 109 mm
Transport Packaging Dimensions Width: 352 mm
Transport Packaging Dimensions Depth: 115 mm
Transport packaging volume: 4,412 dm³
Pallet quantity: 3 616 pcs
Customs tariff: 85363090

Nominal voltage AC: 230 V
Test class: Type 1 + 2
Degree of protection (IP): IP20
Mounting method: On basic element
Construction size: 2 modular spacing
Lightning impulse current (10/350 µs): 100 kA
Specific energy (W/R): 2 500 kJ/Ohm
System configuration TN-S: ✓
Number of poles: 1
System configuration TT: ✓
Integrated backup fuse: ✓
Signalling at the device: Optical
Max. continuous voltage AC: 275 V
